Ultrafine Mill

Ultrafine Mill

Feed Size ≤30mm

Capacity 1-100/h

Exported Countries Cameroon, Tanzania, Congo (DRC), Nigeria, South Africa, Uganda, Albania, Netherlands, United Kingdom, Australia, Tajikistan, Saudi Arabia, Yemen, Mongolia, South Korea, Vietnam, Indonesia, Jordan, Sri Lanka, Pakistan, Palestine, Mexico, Honduras , Nicaragua, etc.

Applied Materials Ultrafine grinding mill can process the non inflammable and explosive minerals with less than 7 Mohs hardness and below 6% humidity, such as calcite, bentonite, limestone, fly ash, kaolin, bentonite, mica, talc, magnesite, pyrophyllite ore, sepiolite, diatomite, barite, gypsum, alum stone, fluorite, rock phosphate, potassium ore, pumice and other minerals.

Get Quote Get latest Price
Service:

7*24 Online/ Free Customized Design/The Latest Price List/Fast Shipping from China/Full Tech Support/After-sale Service

Introduction

Ultrafine grinding mill belongs to Raymond mill, which inherits some advantages of Raymond mill. It can process the non inflammable and explosive minerals with less than 7 Mohs hardness and below 6% humidity, such as calcite, bentonite, limestone, fly ash, etc. Relatively to Raymond mill, ultrafine grinding mill can process wide ranges of materials, which has higher discharging fineness. It has different feeding sizes according to different processed materials and different models, which can be decided according to the specific production requirements.

Advantages

Good stability, high reliability

Small footprint, strong systemic

Creative grinding roller and ring

High-End Durable Material

Super Fine Mesh Number

Environmental Protection Seal

Good product size, through screening rate is 99%

Applications

Coal Mine Non-metallic Ores Ceramics Refractory Materials Water Slag Steel Slag Coal Slag, etc.

Technical Data

Type HGM100 HGM120 HGM130 HGM160 HGM175
Feeding
size (mm)
<20 <20 <25 <30 <35
Size of finished
product (mm)
0.25-0.015 0.25-0.015 0.25-0.015 0.25-0.015 0.25-0.015
Shift output
of different
material
fineness (t/h)
0.8-6 1.2-8 1.8-12 2.8-20 3.5-25
Rotate speed of
central shaft (r/min)
140 140 105 82 75
Diameter of
pulverizing ring (mm)
1075×200 1280×240 1400×240 1770×280 1900×300
Diameter of pulverizing
roller (mm)
320×200 370×240 410×240 450×280 500×300
Main
Motor (kw)
37 55 75 132 160
Fan
Motor (kw)
45 55 75 132 160
Analyzer
motor (kw)
11 15 18.5 22 30

Company and Services

Specialized technical training and instructions

Tracking service, regular inspection equipment

Free technical advice and guidance

The lifelong service and spare parts for customers

Get Service
